Johnson Controls GVC Series User Manual

Johnson Controls
5586996-JSG-A-0120 | Start-Up & Operation Guide
114
BACnet
Attributes
Object
Type
Object
ID
Read/
Write
Short Description
Long
Description
Point Denitions (Units)
CF-2B MV 29938 R CF-2B
Condenser Fan
2B
Displays the command of condenser
fan CF-2B 0 = OFF 1 = ON
C2B MV 29939 R C2B
Compressor 2B
Command
Displays the command of
compressor C2B 0 = OFF 1 = ON
C2B-En MV 29946 R/W C2B-En
Compressor 2B
Enabled
A BAS command to enable
compressor 2B 0 = NO 1 = YES
C2B-S MV 29949 R C2B-S
Compressor 2B
Status
Displays the unit compressor 2B
status
0 = OFF/idle
1 = ON/minimum ON time
2 = ON/normal command
3 = OFF/cooling is disabled
Coast-En MV 29965 R/W Coast-En Coast Enable
A BAS command for unit to enter
coast mode 0 = disable 1 = enable
DAT-SPcong MV 29968 R/W DAT-SPcong
DAT Setpoint
Conguration
A BAS command to select DAT
schedule
0 = xed
1 = OAT reset
2 = supply fan reset
3 = ZT reset
4 = external mode
DownInOccAlm MV 29969 R DownInOccAlm
Unit Down in
OCC Alarm
Displays the unit in occupied alarm
status 0 = normal 1 = alarm
H4 MV 29976 R H4
Heating Stage
Command 4
Displays the command of heating
stage 4 0 = OFF 1 = ON
H4-S MV 29978 R H4-S
Heating Stage 4
Status
Displays the status of heating stage 4
0 = OFF/idle
1 = ON/minimum ON time
2 = ON/normal command
3 = OFF/heating is disabled
H5 MV 29980 R H5
Heating Stage
Command 5
Displays the command of heating
stage 5 0 = OFF 1 = ON
H5-S MV 29982 R H5-S
Heating Stage 5
Status
Displays the status of heating stage 5
0 = OFF/idle
1 = ON/minimum runtime timer
2 = ON/normal command
3 = OFF/heating is disabled
H6 MV 29984 R H6
Heating Stage
Command 6
Displays the command of heating
stage 6 0 = OFF 1 = ON
H6-S MV 29986 R H6-S
Heating Stage 6
Status
Displays the status of heating stage 6
0 = OFF/idle
1 = ON/minimum runtime timer
2 = ON/normal command
3 = OFF/heating is disabled
H7 MV 29988 R H7
Heating Stage
Command 7
Displays the command of heating
stage 7 0 = OFF 1 = ON
H7-S MV 29990 R H7-S
Heating Stage 7
Status
Displays the status of heating stage 7
0 = OFF/idle
1 = ON/minimum runtime timer
2 = ON/normal command
3 = OFF/heating is disabled
Table 32: BACnet Points List (Continued)
