Johnson Controls GVC Series User Manual

Johnson Controls
Start-Up & Operation Guide | 5586996-JSG-A-0120
115
Operation
BACnet
Attributes
Object
Type
Object
ID
Read/
Write
Short Description
Long
Description
Point Denitions (Units)
H8 MV 29992 R H8
Heating Stage
Command 8
Displays the command of heating
stage 8 0 = OFF 1 = ON
H8-S MV 29994 R H8-S
Heating Stage 8
Status
Displays the status of heating stage 8
0 = OFF/idle
1 = ON/minimum runtime timer
2 = ON/normal command
3 = OFF/heating is disabled
HGRB-C MV 30005 R HGRB-C
HGRH Bleed
Valve Command
Displays the command of HGRH
bleed valve 0 = OFF 1 = ON
HRW-C MV 30007 R HRW-C
Heat Recovery
Wheel Command
Displays the command of ERW
0 = OFF 1 = ON
HRW-S MV 30009 R HRW-S
Heat Recovery
Wheel Status
Displays the status of ERW
0 = OFF
1 = max cooling
2 = max heating
3 = blocking protection"
Hum-En MV 30013 R/W Hum-En
Humidication
Enabled
A BAS command to enable
humidication
0 = disable 1 = enable
LowCoolCapAlm MV 30015 R LowCoolCapAlm
Insufcient
Cooling Capability
Alarm
Displays alarm for active temperature
below setpoint in cooling mode
0 = normal 1 = alarm
LowHeatCapAlm MV 30016 R LowHeatCapAlm
Insufcient
Heating Capability
Alarm
Displays alarm for active temperature
below setpoint in heating mode
0 = normal 1 = alarm
Safety2 MV 30023 R Safety2
Local Safety
Command Input 2
Displays the status of local safety
command input 2 0 = false 1 = true
Safety3 MV 30024 R Safety3
Local Safety
Command Input 3
Displays the status of local safety
command input 3 0 = false 1 = true
RunContAlm MV 30027 R RunContAlm
Unit Running
Continuously
Alarm
Displays the status of unit running
continuously alarm
0 = normal 1 = alarm
SFVFD2Flt MV 30031 R SFVFD2Flt
Supply Fan VFD
2 Fault
Displays the status of the supply fan
VFD2 fault 0 = normal 1 = alarm
SMOKE-A MV 30032 R SMOKE-A Smoke Detector
Displays the smoke alarm fault
0 = normal 1 = alarm
SPNoChangeAlm MV 30033 R SPNoChangeAlm
Setpoint Not
Changing Alarm
Displays the status of unit setpoint
not changing alarm
0 = normal 1 = alarm
UVLight-En MV 30036 R/W UVLight-En UV Light Installed
A BAS command that allows UV light
to be enabled 0 = NO 1 = YES
UVLight-Reset MV 30037 R/W UVLight-Reset
UV Light Runtime
Reset
A BAS command that allows UV light
runtime to be reset
0 = OFF 1 = reset
UVLight-Service MV 30039 R UVLight-Service
UV Light Needs
Service
Displays the UV light service alarm
0 = normal 1 = alarm
Condensate
Alarm
MV 30062 R COND-A
Condensate
Alarm
Displays the condensate alarm fault
Table 32: BACnet Points List (Continued)
