Johnson Controls Metasys NCE25 series User Manual

Ordering information
Table 18: NCE25 Ordering Information (Releases 9.0 and 9.0.7 Only)
Product Code
Number
Release Description
MS-NCE25xx-x (Base
Features on Each
NCE25)
N/A Each NCE25 Series model requires a 24 VAC power supply and
includes one RS-232-C serial port, one RS-485 optically isolated
SA Bus port, one USB serial port, one Ethernet port, and an MS-
BAT1020-0 Data Protection Battery. Each NCE25 Series model
has 33 integral I/O points and supports up to 128 additional I/O
points on the SA Bus. Supports BACnet IP network.
MS-NCE2500-0
(Europe only)
9.0.7 Base features with no physical field controller trunk connection.
MS-NCE2506-0
(Europe only)
9.0.7 Base features with no physical field controller trunk connection.
Includes integral display screen.
MS-NCE2510-0 9.0.7 Supports two third-party trunks (Modbus RTU or TCP, M-Bus, or
KNX) and one N2 Bus. The number of supported devices on the
third-party trunk depends on the protocol. For the N2 Bus, up to
32 devices are supported.
MS-NCE2511-0 9.0 Supports two third-party trunks (Modbus RTU or TCP, M-Bus, or
KNX) and one N2 Bus. The number of supported devices on the
third-party trunk depends on the protocol. For the N2 Bus, up to
32 devices are supported. Includes internal modem.
MS-NCE2516-0 9.0.7 Supports two third-party trunks (Modbus RTU or TCP, M-Bus, or
KNX) and one N2 Bus. The number of supported devices on the
third-party trunk depends on the protocol. For the N2 Bus, up to
32 devices are supported. Includes integral display screen.
MS-NCE2517-0 9.0 Supports two third-party trunks (Modbus RTU or TCP, M-Bus, or
KNX) and one N2 Bus. The number of supported devices on the
third-party trunk depends on the protocol. For the N2 Bus, up to
32 devices are supported. Includes integral display screen and
internal modem.
MS-NCE2520-0 9.0 Supports one LonWorks trunk with up to 32 LonWorks devices.
MS-NCE2521-0 9.0 Supports one LonWorks trunk with up to 32 LonWorks devices.
Includes internal modem.
MS-NCE2526-0 9.0 Supports one LonWorks trunk with up to 32 LonWorks devices.
Includes integral display screen.
MS-NCE2527-0 9.0 Supports one LonWorks trunk with up to 32 LonWorks devices.
Includes integral display screen and internal modem.
MS-NCE2560-0 9.0.7 Supports two third-party trunks (Modbus RTU or TCP, M-Bus, or
KNX) and one MS/TP Bus. The number of supported devices on
the third-party trunk depends on the protocol. For the MS/TP
bus, up to 32 devices are supported.
NCE25 Installation Instructions34

Johnson Controls Metasys NCE25 series Specifications

General

Brand	Johnson Controls
Model	Metasys NCE25 series
Category	Controller
Language	English
