VAV Controller—Variable Air Volume (VAV) Controller 15
Table 2 explains the blank attributes. The Operator Workstation User’s
Manual (FAN 634) describes the general procedures for entering and
modifying data.
Table 2: Blank VAV Object Attributes
Attribute Description Entry Values . . .
Object Name
Identifies the object
(i.e., ILC). The object name
cannot be duplicated in the
system.
1 to 8 alphanumeric
characters
Expanded ID
Further identifies the object
(i.e., LC Device 1)
0 to 24 alphanumeric
characters
(Optional)
8. To save the new VAV object, select Save from the Item pull-down
menu. The object is added to the NCM data base.
9. Upload the NCM to make an archive copy of the new object following
the instructions in the Operator Workstation User’s Manual (FAN
634), the Advanced User’s Guide tab, the Uploading and Downloading
Data Bases chapter, the Uploading from the NCM section.
Once you have defined the VAV object, you can modify or monitor its
attribute values online using the VAV object Focus window. See the
Operator Workstation User’s Manual (FAN 634) for more information on
using Focus windows.
Modifying and
Monitoring the
VAV Object
