VAV Controller—Variable Air Volume (VAV) Controller 85
115F116F117FOrdering Information
Table 38: Controller Code Numbers
Code Number Description
AS-VAV110-1
VAV Controller with eight Binary Outputs (Quick Connects)
AS-VAV111-1
VAV Controller with six Binary Outputs and two Analog Outputs
(Quick Connects)
AS-VAV140-1
VAV Controller with screw terminals and eight BOs
AS-VAV141-1
VAV Controller with screw terminals, six BOs and two AOs
AS-VAVDPT1-1*
AS-VAV110-1 Control and DPT-2015-1 for Trane Single Duct
Applications
AS-VAVDPT2-1*
AS-VAV111-1 Control and DPT-2015-1 for Trane Single Duct
Applications
* Refer to Building VAVDPT Applications Application Note (LIT-6363042) in the
Application Specific Controllers Technical Manual (FAN 636.3).
Table 39: Sensor/Transmitters Code Numbers
Code Number Description Type
DPT-2015-1*
Velocity Pressure Transducer
(1.5 in. W.C.)
1 to 5 VDC with 15 VDC Supply
HE-6300
Wall Mount Humidity Sensor 0 to 5 VDC with 12 to 30 VDC
Supply
HE-6310
Duct Mount Humidity 0 to 5 VDC with 12 to 30 VDC
Supply
TE-6000 Series
Temperature Sensor RTD Resistance
TE-6100-11,
TE-6100-12 Series
Zone Temperature Sensor
(for T-4000 Cover)
Nickel, 1000 ohm with Phone
Jack
TE-6300 Series
Temperature Sensor Nickel, Platinum, Silicon
TE-6400 Series
Metastat Zone Temperature
Sensor Series
Resistance
* DPT Transmitters are typically supplied as part of the actuator assembly (ATP Series)
or a controller assembly (VAV DPT Series).
Johnson
Controls Code
Numbers
Controllers
Sensors/
Transmitters
