VAV Controller—Variable Air Volume (VAV) Controller 87
Table 42: Accessories Code Numbers
Code Number Description
AS-CBLPRO-2
Zone Bus Communication Tool
AS-ENC100--0
VAV System Enclosure for Field Installed Systems (Sheet Metal)
AS-TBKIT-0
Five Replacement N2 Bus and Five Power Terminal Block Connectors
AS-XFR050-0
Transformer (50 VA)
AS-ZTU100-1*
Zone Terminal
EN-EWC10-0
Enclosure (UPM)
EN-EWC15-0
Enclosure with 50 VA Transformer (UPM)
MM-CVT101-0
RS-232/RS-485 Converter for N2 Download/Commissioning with
HVAC PRO for Windows
P32 Series
Air Flow Switch
TE-6001-961
Momentary Button Kit for Temporary Occupancy or Boost Modes
(for TE-6100-11,12 only)
WS-WINPRO-0
Configuration Tools Software (includes HVAC PRO for Windows)
WS-WINPRO-6
Configuration Tools Software Upgrade
(includes HVAC PRO for Windows)
Y65XX-X Series
Transformer Option (24/120/220/277-480 VAC to 24 VAC)
* Note: The AS-ZTU100-1 supports both AS-VAVxxx-0 and AS-VAVxxx-1 models.
The AS-ZTU100-0 supports AS-VAVxxx-0 models only.
The following tables list code numbers and descriptions for VAV
Controller equipment requirements. This equipment is available from:
Anixter
4701 W. Schroeder Drive
Brown Deer, WI 53223
(414) 355-0222 (in Milwaukee)
1-800-242-5575 (structure wiring)
1-800-447-8565 (wire and cable)
Use the following table to order preconfigured cables from the factory.
Table 43: Preconfigured Cables
Description Cable Length Part
Feet Meters Number
RJ45 Straight-through Cable Assembly Non-plenum
25 7.5 889158
Non-keyed plugs
50 15 889161
24 Gauge/0.6 mm diameter
100 30 889166
8 Conductor
Solid Wire
RJ45 Straight-through Cable Assembly Plenum
25 7.5 889315
Non-keyed plugs
50 15 889318
24 Gauge/0.6 mm diameter
100 30 889324
8 Conductor
Solid Wire
Accessories
118F119F120FVendor Code
Numbers
