VAV Controller—Variable Air Volume (VAV) Controller 89
Specifications
Table 45: General Specifications
Product Name
Variable Air Volume (VAV) Controller
Product Code Numbers
AS-VAV100-0, AS-VAV101-0;
AS-VAV110-1, AS-VAV111-1;
AS-VAV140-1, AS-VAV141-1
Power Input
20-30 VAC @ 10 VA
Power Draw
VAV with sensors/transmitters: 10 VA (400 mA)
Ambient Operating
Conditions
32 to 122F/0 to 50C
10 to 90% RH
Ambient Storage
Conditions
-40 to 158F/-40 to 70C
10 to 90% RH
Dimensions (H x W x D)
6.5 x 6.4 x 2.2 in./165 x 163 x 56 mm without enclosure
6.8 x 7.3 x 4.7 in./173 x 185 x 119 mm with the AS-ENC100-0 enclosure
Shipping Weight
1.4 lb./0.64 kg
Processor
80C652 @ 11 MHz
Word Size
8 bit
EEPROM Size
8k byte (2k byte for VAV 100/101)
ROM/EPROM Size
64k byte
RAM Size
8k byte
Interfaces
N2 and Zone Bus
Inputs/Outputs
8 Analog Inputs (0-10 VDC)
4 Binary Inputs
0/2 Analog Outputs (0-10 VDC)
8/6 Binary Outputs (24 VAC Triacs)
Standard Compliance
IEEE 472
IEEE 518
IEEE 587 Category A
FCC Part 15, Subpart J, Class A
UL 916, Energy Management Listed, Class PAZX
VDE 0871 Class B
Agency Listings
UL 916 Listed and CSA Certified as part of the Metasys Network.

Johnson Controls METASYS VAV111 Specifications

General

Brand	Johnson Controls
Model	METASYS VAV111
Category	Controller
Language	English
