Figure 3-5: Live System Upgrade: Connecting Panels and P2000 Workstations
to the Regional Server
P2000 Server version 3.10
Hub
Panels and P2000 Workstations
version 3.10
WAN
CENTRAL SITE
P2000 Server version 34
Enterprise Configuration
REGIONAL SITE
P2000 Server version 3.10
Enterprise Configuration
Enterprise Configuration Merging Data Between Sites
