Item Specification
Input Power 24 VDC @ 1.5 amps maximum
Lock Output 12/24 VDC (up to 8 W)
Reader Interface • 2-wire Wiegand (up to 256 bits)
• 5/12/24 VDC (up to 5 W)
• Red indicator
• Green indicator
General Purpose Inputs Resistive load
General Purpose Outputs 0-12 VDC
Communications 2-wire RS-485
Certifications • UL 294 (Access control)
• UL 1076 (Proprietary alarm unit)
• CSA/CUL C22.2 No. 205
• FCC, Class B
• CE Mark
•C-Tick
Mounting Specifications •DIN rail
• Flat surface
• Field wiring assembly and control electronics are on separate
p
anel
s to aid in ease of installation
Dimensions 7 H x 4.5 W x 2.25 D inches
(17.5 cm x 11.25 cm x 5.5 cm)
Ambient Temperature 32º to 122º F (0º to 50ºC)
Humidity 10 to 85% non-condensing
Ventilation Cabinets require free movement o
f air over all exposed surfaces
Hardware Installation S300-DIN-RDR2S Module
36 24-10239-413 Rev. A
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2010 Johnson Controls, Inc.
MAINTENANCE
This chapter provides maintenance instructions, operational testing procedures,
troubleshooting guidelines, and information on replacement parts.
Routine Maintenance
 Perform the following routine maintenance for the RDR2S:
1. Periodically check the continuity of the grounding
circuit.
2. Perform operational testing monthly (see “Testing Procedure” on page 37).
3. Replace the lithium battery every five y
ears or after extended (five days)
power interruption (Panasonic CR 2025 or equivalent). See “Real Time
Clock Battery (Lithium Battery) Replacement” on page 37.
4. If installed, replace the lead-acid backup battery every three years (Power
Sonic PS-1270, 12 VDC,
7 Ah for the large enclosure; Power Sonic
PS-1228, 12 VDC, 2.8 Ah for the small enclosure).
