S321-IP Network Controller Hardware Installation
24-10239-480 Rev. F
7
Reference – These signals are referenced to logic ground (COM).
Protection – Each signal has a 30 volt transient voltage suppressor
between it and system ground.
Relay Output Points
Description of Signals – NC, NO, and COM are the three connections to
a single pole, double throw relay. The following are the relay outputs:
Reference – The relay is a dry contact relay rated at 1 A at 24 VDC/
VAC, 25 VA maximum.
Reader Power
Description of Signals – 250 mA at 12 VDC is provided for each reader.
Protection – There is a 750 mA PTC re-settable fuse.
Network Connection
RJ45 connector – Use this connector to connect the S321-IP to the
network. The S321-IP communicates with the P2000 server via 10/
100Base-T Ethernet, using the TCP/IP protocol.
C
ABLE REQUIREMENTS
This table describes the recommended cable to use when wiring the S321-IP.
• Reader 1 Strike
• Reader 1 Shunt
• Reader 2 Strike
• Reader 2 Shunt
Description Recommended Cable Type Maximum Segment Length
S321-IP to Power
Supply
1
Listed, 18 AWG, hook-up
wire
Wire should fit within the enclosure.
S321-IP to Host Listed, Category 5, 24 AWG,
solid, 2 pair or 4 pair type.
354 ft (100 m). Cable, RJ45 connector,
and RJ45 crimp tool to be supplied by
customer.
Door Contact Belden 8442, 1 twisted,
unshielded pair, 22 AWG
500 ft. (152 m)
Door Strike and
Shunt
Belden 9740, 1 twisted,
unshielded pair, 18 AWG
Depends on power requirements of the
door strike. Do not reduce voltage to
the strike more than 10% over the 18
AWG wire, measured when energized.
