S321-IP Network Controller Hardware Installation
24-10239-480 Rev. F
16
To log on to the S321-IP controller’s user interface:
1. From a web browser, enter the following URL, using either the IP
address or name of the S321-IP:
http://name (the default name is s321ip), or
http://IP Address (the default static IP address is 192.168.0.1),
2. Enter your User Name and Password. Your user name and password
are defined on the HTTP configuration page.
If accessing the S321-IP user interface for the first time, enter
the following in the exact letter case, as shown:
User Name: admin
Password: PASS
NOTE: If you cannot successfully log on to the S321-IP user interface, consult
with the Network Administrator for assistance.
3. Click OK. The Main menu options appear.
To log off from the S321-IP controller’s user interface:
1. To log off from the S321-IP user interface, click the Logout link at
the upper-right corner of any page or simply close the browser
window.
In addition, the S321-IP user interface automatically logs off
the current user if the system does not detect any activity for
20 minutes.
T
HE S321-IP USER INTERFACE
This section briefly describes the S321-IP user interface, which consists of:
Menu Bar – Each menu item on this bar reveals a different set of menu
options, which enable you to perform specific functions, such as configuring,
monitoring, or operating the S321-IP.
Menu Options – These options are a collection of functions associated with
the menu selected on the Menu bar. To select a menu option, simply click the
text link or the graphic icon next to it, if applicable (not all menu options have
an associated icon).
