T600HCx-3 Single-Stage Thermostats Installation Instructions12
To set the time schedule for a two-event schedule,
follow the steps in Table 5. See Table 7, Events 1
and 2, for an example of a two-event office schedule.
Programming the Daily Schedule – Four-Event
(T600HCP-3)
The schedule-setting menu is used to enter the
occupied and unoccupied states for each day of the
week. The schedule-setting menu reflects either a
two- or four-event schedule per day, based on what
was selected in the 2/4event parameter during the
configuration process. If the schedule-setting menu
does not reflect a four-event schedule, select four
events in the 2/4event parameter of the Installer
Configuration Menu.
When changing the time, press the UP/DOWN arrow
keys once to change the time in 1-minute increments;
press and hold down the keys to change the time in
30-minute increments.
Note: Programming one of the digital inputs to remote
NSB disables the menu.
To set the time schedule for a four-event schedule,
follow the steps in Table 6. See Table 7 for an example
of a four-event office schedule.
Table 5: Programming the Daily Schedule –
Two-Event (Part 1 of 2)
Thermostat
Display
Description
Press the MENU key while in the
Status Display Menu to enter the
Main User Menu.
Press the NO key to all prompts until
the schedule set prompt appears on
the display. Press the YES key to
enter the scheduling menu.
Press the YES key to set the
schedule for Monday or press the NO
key to advance to Tuesday.
Press the YES key to set the
occupied start time for Monday or
press the NO key to advance to
Tuesday. Selecting NO leaves the
thermostat in the unoccupied state
for the entire day.
Press the UP/DOWN arrow keys to
set the occupied start time. Press the
YES key to enter the time.
Press the UP/DOWN arrow keys to
set the unoccupied start time. Press
the YES key to enter the time.
Press the YES key to set the
schedule for Tuesday or press the
NO key to advance to Wednesday.
Press the YES key to copy the
schedule from the previous day.
Press the NO key to set a different
schedule.
RoomTemp
75.0

F
Schedule
set? Y/N
Monda
y
set? Y/N
Occupied
day? Y/N
Occupied
12:00 AM
Unoccup
12:00 AM
Tuesda
y
set? Y/N
Cop
y
Y/N
previous
If the YES key was pressed, the next
prompt is for Wednesday. Repeat the
procedure for the rest of the days of
the week.
After setting the schedule for all the
days of the week, following the last
entry for Sunday, press the YES key
to return to the Status Display Menu
or press the NO key to start again at
Monday.
Table 6: Programming the Daily Schedule –
Four-Event (Part 1 of 2)
Thermostat
Display
Description
Press the MENU key from the Status
Display Menu to enter the Main User
Menu.
Press the NO key to all prompts until
the schedule set prompt appears on
the display. Press the YES key to
enter the scheduling menu.
Table 5: Programming the Daily Schedule –
Two-Event (Part 2 of 2)
Thermostat
Display
Description
Wednesda
set? Y/N
Exit?
Y/N
RoomTemp
75.0

F
Schedule
set? Y/N
