T7200
P/N 24-85784-00186 Rev. A_Issue Date: 09 2018
INSTALLATION INSTRUCTIONS FOR THE TECHNICIAN / FITTER
READ THIS INSTRUCTION SHEET AND THE SAFETY WARNINGS CAREFULLY BEFORE INSTALLING AND
SAVE IT FOR FUTURE USE
REPAIR AND REPLACEMENT
Do not attempt to repair the T7 Series thermostat. In case of an improperly functioning control, contact the nearest Johnson Controls® representative, and
specify the desired product code number. When contacting the supplier for a replacement please state the type/model number of the control located on the
data plate or cover label.
IMPORTANT
Use this T7 Series Thermostat only as an operating control. Where failure of malfunction of the T7 Series Thermostat could lead to personal injury or
property damage to the controlled equipment or other property, additional precautions must be designed into the system. Incorporate and maintain other
devices such as supervisory or alarm systems or safety or limit controls intended to warn of, or protect against, failure or malfunction of the T7 Series
Thermostat.
Do not install this thermostat in condensing, wet, or damp environments. Moisture may cause damage to the thermostat.
Do not remove PCB from the enclosure cover. Removing the PCB from the enclosure cover voids the product warranty.
Make all wiring connections in accordance with local, nation, and regional regulations. Do not exceed the T7 Series thermostat’s electrical ratings.
WARNING
Disconnect power supply before making electrical connections. Contact with components carrying hazardous voltages can cause electrical shock and may
result in severe personal injury or death.
Risk of Electrical Shock: Ground the thermostat according to local, national, and regional regulations. Failure to ground the thermostat may result in
electrical shock and severe personal injury and death.
Risk of Electrical Shock and Property Damage: Insulate and secure each unused wire lead before applying power to the thermostat.
Failure to insulate and secure each unused wire lead may result property damage, electrical shock, and severe personal injury or death.
English
PARAMETER SETTING (PART 1/2)
Press
and
button for 5 seconds at power off mode to get in parameter list. Press M button to scroll the list and use
and
button to change
parameter value.
Code
T7200-
TB21-...JS0
T7200-
TF20-...JS0 Parameter Name Default Function
01
Application 00
T7200-TB21-...JS0
00: 2-pipe ON/OFF valve with EC Motor Control
01: 4-pipe ON/OFF valve with EC Motor Control
02: 2-pipe ON/OFF three wire relay valve with EC Motor Control
03: 2-pipe ON/OFF valve with TiO2/ESP relay with EC Motor Control
04: 2-pipe ON/OFF valve with floor heating with EC Motor Control
05: Water source heat pump with EC Motor Control
06: Single fan speed AHU
07: 2-pipe Proportional valve, three speed fan
T7200-TF20-...JS0 ON/OFF Control
00: 2-pipe ON/OFF valve
01: 4-pipe ON/OFF Valve
02: 2-pipe ON/OFF three-wire relay valve
03: 2-pipe ON/OFF valve with TiO2/ESP relay
04: 2-pipe ON/OFF valve with floor heating
05: Water source heat pump
02
Upper setpoint limit 35°C Setting range 2 to 40°C (36 to 99°F)
03
Lower setpoint limit 5°C Setting range 0 to 38°C (32 to 95°F)
04
Cooling setpoint unoccupied 26°C Setting range 22 to 32°C (72 to 90°F)
05
Heating setpoint unoccupied 18°C Setting range 10 to 21°C (50 to 70°F)
06
Frost protection 00
00: On
01: Off
07
Frost protection setpoint 5°C Setting range 0 to 20°C (32 to 68°F)
09
1
Fan mode when unoccupied 00
00: Low speed
01: Set speed
10
2
--- ECM Min voltage 3V Min voltage below which the fan output is 0%, range 0-10 V. (0.5 V)
11
2
--- ECM Max voltage 10V Max voltage above which the fan output is 100%, range 0-10 V
12
2
--- ECM cut off relay (F-ON) 00
00: Disabled
01: Enabled
13
Restart after power failure 00
00: Keep last status
01: On
02: Off
14
Keypad lock 00
00: No lock
01: Lock all keys
02: Lock the keys except Fan Speed and Temp Adjustment keys
03: Lock the ON/OFF and Timer keys
04: Lock the keys except ON/OFF key
...Continued...
