T7200
P/N 24-85784-00186 Rev. C Issue Date: 01 2020
English
PARAMETER SETTING (PART 1/2)
Press
and
button for 5 seconds at power o mode to get in parameter list. Press M button to scroll the list and use
and
button to change
parameter value.
Code
T7200-
TB21-9JS0,
T7200-
TB21-9JS1
T7200-
TF20-9JS0,
T7200-
TF20-9JS1 Parameter Name Default Function
01
■ ■
Upper setpoint limit 35°C Setting range 2°C to 40°C (36°F to 99°F)
02
■ ■
Lower setpoint limit 5°C Setting range 0°C to 38°C (32°F to 95°F)
03
■
■
Application 00
T7200-TB21-9JS0, T7200-TB21-9JS1
00: 2-pipe ON/OFF valve with EC Motor Control
01: 4-pipe ON/OFF valve with EC Motor Control
02: 2-pipe ON/OFF three wire relay valve with EC Motor Control
03: 2-pipe ON/OFF valve with TiO2/ESP relay with EC Motor Control
04: 2-pipe ON/OFF valve with floor heating with EC Motor Control
05: Water source heat pump with EC Motor Control
06: Single fan speed AHU
07: 2-pipe Proportional valve, three speed fan
T7200-TF20-9JS0, T7200-TF20-9JS1
00: 2-pipe ON/OFF valve
01: 4-pipe ON/OFF Valve
02: 2-pipe ON/OFF three-wire relay valve
03: 2-pipe ON/OFF valve with TiO2/ESP relay
04: 2-pipe ON/OFF valve with floor heating
05: Water source heat pump
04
■ ■
Cooling setpoint unoccupied 26°C Setting range 22°C to 32°C (72°F to 90°F)
05
■ ■
Heating setpoint unoccupied 18°C Setting range 10°C to 21°C (50°F to 70°F)
06
■ ■
Frost protection 00
00: On
01: Off
07
■ ■
Frost protection setpoint 5°C Setting range 0°C to 20°C (32 °Fto 68°F)
08
■ ■
Fan speed in AUTO mode in
deadband (room temperature
reach set point)
01
00: Fan off
01: Low speed
09
■
1
■
Fan mode when unoccupied 00
00: Low speed
01: Set speed
10
■
2
--- ECM Min voltage 3V Min voltage below which the fan output is 0%, range 0 V -10 V. (0.5 V)
11
■
2
--- ECM Max voltage 10V Max voltage above which the fan output is 100%, range 0-10 V
12
■
2
--- ECM cut off relay (F-ON) 00
00: Disabled
01: Enabled
13
■ ■
Restart after power failure 00
00: Keep last status
01: On
02: Off
14
■ ■
Keypad lock 00
00: No lock
01: Lock all keys
02: Lock the keys except Fan Speed and Temp Adjustment keys
03: Lock the ON/OFF and Timer keys
04: Lock the keys except ON/OFF key
...Continued...
INSTRUCTIONS
On/O Setting: Press to turn on, press again to turn o, close the fan and valve.
Mode Selection: Press M to change the working mode, for cooling, for heating, and for venting.
Temperature Setting: Press either or button to increase or decrease the temperature by 0.5°C.
Fan Speed Adjustment: Press to switch the fan mode, auto ash, high , medium , low fan.
Delay On/O setup: Press and hold button 5 seconds, then “ON” appears, press button to switch On or O delay,
then press or to adjust the minute by 30 minutes.
Note: Time-On/O setting performs only once within one day.
Delay On/O Cancel: Press and hold button 5 seconds, then “ON” appears, press button to switch to check On or
O delay time, then press or adjust the time to “00:00”.
Lock setup: If Lock function is enabled, the thermostat locks automatically after 30 seconds unused.
Unlock function: Press and hold the button for 5 seconds to unlock. The thermostat locks automatically after 30
seconds unused.
Tio2/ESP Manual: When Tio2/ESP function is set to Manual, press button once, to switch Tio2/ESP On or O.
To Next Page
