Johnson Controls T9200 - Page 3

T9200
P/N 24-11446-00018 Rev. B Issue Date: 11 2020
T9200-TB21-1JS0
2-pipe FCU, three speed fan
2管制比例阀，三速风机
100-240 VAC 50/60Hz L
N
N
R3L R1
R2
FAN
GND
OCCAO
Cool / Heater
HiMedLow
GND
L
N
2-pipe FCU (relay), ECM
2管制开关阀，ECM风机
0-10 V
100-240 VAC 50/60Hz
ECM
FAN
OCC
AO
Cool/Heat
N
R3L R1
R2
Heat
GND
L
N
4-pipe FCU (relay), ECM fan
4管制开关阀，ECM风机
100-240 VAC 50/60Hz
ECM
FAN
OCC
AO
Cool
0-10 V
N
R3L R1
R2
GND
L
N
2-pipe FCU, 3 wires (relay),
ECM fan
2管制三线阀，ECM风机
100-240 VAC 50/60Hz
ECM
FAN
OCC
AO
Off
On
0-10 V
N
R3L R1
R2
GND
L
N
2-pipe FCU with floor heater,
ECM fan
2管制开关阀带地暖，ECM风机
100-240 VAC 50/60Hz
ECM
FAN
OCC
AO
Cool/
Heat
Floor
Heater
0-10 V
N
R3L R1
R2
GND
L
N
2-pipe FCU with TiO2/ESP, ECM
2管制开关阀+ TiO2/ESP,
ECM风机
100-240 VAC 50/60Hz
ECM
FAN
OCC
AO
Cool/
Heat
0-10 V
TiO2
ESP
N
R3L R1
R2
GND
L
N
water source heat pump
水源热泵
100-240 VAC 50/60Hz
OCCAO
ECM
FAN
0-10 V
CMP
RV
N
R3L R1
R2
