Sample Wiring Diagrams

Outdoor Sensor: ACC-RSEN Temperature Sensor 10K ohm sensor at

77F/25C. Negative Temperature Coefﬁcient.

W1/O/B

W3/AUX

10K Thermistor

Outdoor Sensor

Use 18-22 gauge thermostat wire.

W1/O/B

W3/AUX

10K Thermistor

Remote Sensor

Use 18-22 gauge thermostat wire.

SENSOR

ACC-RSEN

Installation Instructions
