85
Installation Instructions
C
R
G
Y1
Y2
W1/O/B
W2
W3/AUX
C
R
G
Y1
Y2
W1/O/B
W2
W3/AUX
Humidification
System
DEHUM/
HUM
Dehumidification Terminal
on Equipment
SENSOR
SENSOR
Sample Wiring Diagrams
Use 16-24 gauge
thermostat wire.
Use 16-24 gauge
thermostat wire.
AUX Output Usage
must be set for Hum
AUX Output Usage
must be set for Dehum
Humidification
Dehumidification
