Johnson Controls TCSC Series - Service and Clearance Requirements (Optional Drain Pan); Clearance Dimensions for Optional Drain Pan

JOHNSON CONTROLS
16
FORM 130.13-NOM8 (1021)
MODEL TCSC SIZES 07-23 OPTIONAL DRAIN PAN & AUXILIARY PAN
Service And Clearance Requirements
Drawings not for installation purposes. Refer to unit and size-specic
submittal drawings for installation.
2-1/2"
64
FLOW
PRIMARY
AIR
FLOW
AIR
INDUCED
AIR FLOW
TOP VIEW
DRAIN PAN
OPTIONAL
DRAIN
CONNECTION
OPTIONAL
"A"
DRAIN PAN
REMOVAL
BOTTOM ACCESS
DISCHARGE END VIEW
"B"
21"
533
3"
76
SIDE VIEW
NOTES:
1. All dimensions in Inches [millimeters]. All dimensions
±
1/4" [6mm].
2. Left Hand unit shown, Right Hand unit opposite.
3. Standard Electrical Enclosure shown, 90° Electrical Enclosure Unit same as shown.
AUXILIARY PAN
OPTIONAL
DRAIN PAN
UNIT
SIZES
COOLING
COIL
# ROWS
"A" "B"
07/10
2 - 4
8-1/2"
[216]
42"
[1067]
6 - 8
13"
[330]
12-25
2 - 4
8-1/2"
[216]
47"
[1194]
6 - 8
13"
[330]
PAGE 1 OF 1
10-80118-J
A
5/28/21
DIMENSIONS ARE IN INCH [MM] FORMAT
+/- 1/8 [3] UNLESS OTHERWISE NOTED
DRAWING NO
TITLE:
REV
SHEET
DATE
ALL DRAWINGS ARE SUBJECT TO CHANGE
WITHOUT PRIOR NOTICE
DO NOT SCALE DRAWING
SUBMITTAL DRAWING
THIS DRAWING CONTAINS PROPRIETARY DATA. UNAUTHORIZED DISCLOSURE,
REPRODUCTION, OR USE IS STRICTLY PROHIBITED WITHOUT WRITTEN PERMISSION.
UNCONTROLLED WHEN PRINTED
MODEL TCSC DRAIN & AUX PAN,
EXTERNAL SPACE REQUIREMENTS
