Johnson Controls TCSC Series User Manual

JOHNSON CONTROLS
21
FORM 130.13-NOM8 (1021)
MODEL TCSC SIZES 07-23
3/8” Hot Water Coil Connections, Multiple Circuits
4"
102
A
B
C
AIR
SIDE VIEW
LEFT HAND SHOWN
RIGHT HAND OPPOSITE
RETURN (OUT)
SUPPLY (IN)
D
FRONT VIEW
LEFT HAND SHOWN
RIGHT HAND OPPOSITE
(OPTIONAL)
NOTES:
1. All dimensions are in inches [millimeters]
2. All dimensions may vary in
1/2 [13mm].
Metric values are soft conversion.
3. All drawings are subject to change without notice.
4. Connection Size: 5/8 ODM (1/2" NOM.)
5. This sheet applies to multiple circuits only.
For single circuit coils refer sheet no 2.
FOR MULTIPLE CIRCUITS
COIL ONLY
Unit Size
Coil
Rows
(3/8"
Coil)
A B C
D
7/10
1
5-7/8"
[150]
3-1/8"
[78]
1"
[25]
4-3/8"
[111]
2
5-7/8"
[150]
3-1/4"
[82]
7/8"
[22]
4-3/8"
[111]
3
5-7/8"
[150]
3-1/4"
[82]
1 3/4"
[44]
4-3/8"
[111]
4
5-7/8"
[150]
4-1/8"
[104]
2-5/8"
[66]
4-3/8"
[111]
15/20/23
1
7-1/4"
[185]
3-1/8"
[78]
1"
[25]
4-3/8"
[111]
2
7-1/4"
[185]
3-1/4"
[82]
7/8"
[22]
4-3/8"
[111]
3
7-1/4"
[185]
3-1/4"
[82]
1 3/4"
[44]
4-3/8"
[111]
4
7-1/4"
[185]
4-1/8"
[104]
2-5/8"
[66]
4-3/8"
[111]
35/45
[TCSB &
TCSQ ONLY]
1
7-1/16''
[180]
3-1/8"
[78]
1"
[25]
4-1/2"
[114]
2
7-1/16''
[180]
3-1/4"
[82]
7/8"
[22]
4-1/2"
[114]
3
7-1/16''
[180]
3-1/4"
[82]
1 3/4"
[44]
4-1/2"
[114]
4
7-1/16''
[180]
4-1/8"
[104]
2-5/8"
[66]
4-1/2"
[114]
PAGE 1 OF 2
10-80048-J
C
4/29/2021
DIMENSIONS ARE IN INCH [MM] FORMAT
+/- 1/8 [3] UNLESS OTHERWISE NOTED
DRAWING NO
TITLE:
REV
SHEET
DATE
ALL DRAWINGS ARE SUBJECT TO CHANGE
WITHOUT PRIOR NOTICE
DO NOT SCALE DRAWING
SUBMITTAL DRAWING
MODEL TCSB, TCSQ & TCSC
HOT WATER, 3/8" DIA COIL CONNECTIONS
THIS DRAWING CONTAINS PROPRIETARY DATA. UNAUTHORIZED DISCLOSURE,
REPRODUCTION, OR USE IS STRICTLY PROHIBITED WITHOUT WRITTEN PERMISSION.
UNCONTROLLED WHEN PRINTED
