Johnson Controls TCSC Series User Manual

JOHNSON CONTROLS
39
FORM 130.13-NOM8 (1021)
FACE AREA, FREE AREA, AND FILTER SIZES
NOTES:
1. All lters are an optional feature. For optimal unit performance, lter type should
be selected during the unit selection and ordering process.
2. Filter sizes are nominal, measured in inches [millimeters]
3. Coil and lter face areas are measured in square feet [square meters]
THROWAWAY / PLEATED 1” AND 2” FILTERS
C:\Users\jklemmj\Desktop\Project Keep\Series Flow Redesign Project - 2020\12 - Technical Information and Tables\2 - Face Area and Filter Size Tables\ETI\CRC\Engineering - CRC -
Face Area Table
Face Area & Filter Sizes
uncontrolled when printed 2/24/2021
UNIT
SIZE
HEATING COIL
FACE AREA
COOLING COIL
FACE AREA
NOMINAL FILTER SIZES
1" THROWAWAY
FACE AREA
2" THROWAWAY
FACE AREA
1" PLEATED
GROSS MEDIA AREA
2" PLEATED
GROSS MEDIA AREA
07 0.83 [0.08] 2.69 [0.25] (1) 10.5 x 31 [267 x 787] 2.12 [0.2] 2.12 [0.2] 3.7 [0.34] 6.4 [0.59]
10 1.33 [0.12] 2.69 [0.25] (1) 10.5 x 31 [267 x 787] 2.12 [0.2] 2.12 [0.2] 3.7 [0.34] 6.4 [0.59]
15 2 [0.19] 3.75 [0.35] (1) 13.25 x 35.75 [337 x 908] 3.12 [0.29] 3.12 [0.29] 5.5 [0.51] 9.4 [0.87]
20 2.67 [0.25] 3.75 [0.35] (1) 13.25 x 35.75 [337 x 908] 3.12 [0.29] 3.12 [0.29] 5.5 [0.51] 9.4 [0.87]
23 2.67 [0.25] 3.75 [0.35] (1) 13.25 x 35.75 [337 x 908] 3.12 [0.29] 3.12 [0.29] 5.5 [0.51] 9.4 [0.87]
