JOHNSON CONTROLS
30
FORM 130.13-NOM8 (1021)
MODEL TCSC SIZES 07-23
1/2” Coil Valve Package Connections
B
9 1/4"
235
SEE NOTE 4
10 3/4"
273
SEE NOTE 4
AIR
ON/OFF 2-WAY VALVE PACK
(LEFT HAND SHOWN)
(RIGHT HAND OPPOSITE)
SUPPLY (IN)
RETURN (OUT)
SEE NOTE 5
A
4"
102
11 7/8"
302
8 3/4"
222
SEE NOTE 4
SEE NOTE 6
D
4 3/4"
119
9 1/4"
235
SEE NOTE 4
10 1/4"
260
SEE NOTE 4
AIR
ON/OFF 3-WAY VALVE PACK
(LEFT HAND SHOWN)
(RIGHT HAND OPPOSITE)
SUPPLY (IN)
RETURN (OUT)
SEE NOTE 5
C
1 7/8"
47
11 7/8"
302
8 3/4"
222
SEE NOTE 4
SEE NOTE 6
NOTES:
1. All dimensions are in inches [millimeters]
All dimensions may have
1/2 [13mm]
variation.
Metric values are soft conversion.
2. All drawings subject to change without
notice.
3. Consult unit selection summary
for valve package components and
specifications. Valve package end point
dimensions are fixed value,regardless of
selected valve package components.
4. Dimensions indicate space requirement
for valve-package install. Additional
service space requirements depend on
option selections.
5.Valve package support structure can be
removed.
6. SS flexible hoses are available but not
shown.
UNIT SIZE COIL ROWS A B C D
07/10
1/2/3
5-5/8"
[143]
12-1/2"
[319]
7-3/4"
[198]
10-1/8"
[259]
4
5-5/8"
[143]
12-1/4"
[311]
7-3/4"
[198]
9-7/8"
[251]
15/20/23
1/2/3
7-1/16"
[179]
12-1/2"
[319]
9-1/4"
[235]
10-1/8"
[259]
4
7-1/16"
[179]
12-1/4"
[311]
9-1/4"
[235]
9-7/8"
[251]
35/45
[TCSB & TCSQ
ONLY]
1/2/3
7-1/16"
[179]
12-1/2"
[319]
9-1/4"
[235]
10-1/8"
[259]
4
7-1/16"
[179]
12-1/4"
[311]
9-1/4"
[235]
9-7/8"
[251]
PAGE 2 OF 3
10-80051-J
C
4/29/2021
DIMENSIONS ARE IN INCH [MM] FORMAT
+/- 1/8 [3] UNLESS OTHERWISE NOTED
DRAWING NO
TITLE:
MODEL TCSB, TCSQ & TCSC 1/2” DIA, HW
COIL, VALVE PACKAGE CONNECTIONS
REV
SHEET
DATE
ALL DRAWINGS ARE SUBJECT TO CHANGE
WITHOUT PRIOR NOTICE
DO NOT SCALE DRAWING
SUBMITTAL DRAWING
THIS DRAWING CONTAINS PROPRIETARY DATA. UNAUTHORIZED DISCLOSURE,
REPRODUCTION, OR USE IS STRICTLY PROHIBITED WITHOUT WRITTEN PERMISSION.
UNCONTROLLED WHEN PRINTED
