Johnson Controls TEC3630 Series User Manual

TEC3000 Series Single- or Two-Stage Economizer Thermostat Controllers Installation Instructions
28
Menus and Submenus
In the following table, the * indicates that the menus depend on your configuration.
Table 10: Menus and Submenus (Part 1 of 9)
Level 1 Level 2
(LCD Screen Name)
Level 3
(Default Values)
Available Values
1
Setpoints Occ Cooling Setpoint 72°F (22°C) 55 to 85°F (13 to 30°C)
Occ Heating Setpoint 68°F (20°C) 55 to 85°F (13 to 30°C)
Unocc Cooling Setpoint 80ºF (27°C) 55 to 85°F (13 to 30°C)
Unocc Heating Setpoint 60°F (15°C) 55 to 85°F (13 to 30°C)
Stby Cooling Setpoint 74°F (23°C) 55 to 85°F (13 to 30°C)
Stby Heating Setpoint 66°F (19°C) 55 to 85°F (13 to 30°C)
Occ Setpoint Select Setpoint Offset Min and Max Setpoint or Setpoint Offset
Heat Cool Setpoint Mode Individual
Setpoints
Common Setpoint or Individual Setpoint
Max Heating Setpoint* 68°F (20°C) The range (in degrees) from the Min
Heating Setpoint temperature to the Min
Cooling Setpoint temperature minus 1°F
(0.55°C). (The cooling temperature
always needs to be 1°F [0.55°C] above
the heating temperature.)
*These values only appear when Heat
Cool Setpoint Mode == Individual
Setpoints and Occ Setpoint Select ==
Min and Max Setpoint.
Min Heating Setpoint* 60°F (15°C) 45°F (7.22°C) to Max Heating Setpoint
*These values only appear when Heat
Cool Setpoint Mode == Individual
Setpoints and Occ Setpoint Select ==
Min and Max Setpoint.
Max Cooling Setpoint* 80ºF (27°C) Min Cooling Setpoint to 100°F (37.77°C)
*These values only appear when Heat
Cool Setpoint Mode == Individual
Setpoints and Occ Setpoint Select ==
Min and Max Setpoint.
Min Cooling Setpoint* 72°F (22°C) The range (in degrees) from the Max
Heating Setpoint temperature plus
1°F (0.55°C) to the Max Cooling Setpoint
temperature.
*These values only appear when Heat
Cool Setpoint Mode == Individual
Setpoints and Occ Setpoint Select ==
Min and Max Setpoint.
Max Setpoint* 80ºF (27°C) Min Setpoint to 100°F (37.77°C)
*These values only appear when Heat
Cool Setpoint Mode == Common
Setpoint and Occ Setpoint Select == Min
and Max Setpoint.
Min Setpoint* 60°F (15°C) 45°F (7.22°C) to Max Setpoint
*These values only appear when Heat
Cool Setpoint Mode == Common
Setpoint and Occ Setpoint Select == Min
and Max Setpoint.
