Menu level 1 Menu level 2 Menu level 3 Menu level 4
Control values Motor Values
Current
Power
Speed
Speed ref.
Frequency
Final speed
Voltage
Torque Nm
Torque %
Mains voltage
DC bus voltage
U phase temp.
V phase temp.
W phase temp.
Heatsink temp.
Rectifier temp.
Ambient temp. board
Control
Control
Control (VSD only)
(VSD/Modbus only)
(VSD/Modbus only) /DA
(VSD/Modbus only) /LS
(VSD/Modbus only)
(VSD/Modbus only)
(VSD/Modbus only) /DA
(VSD/Modbus only) /LS
(VSD/Modbus only)
(VSD/Modbus only) /LS
(VSD/Modbus only) /LS
(VSD/Modbus only /LS)
(VSD/Modbus only /DA)
(VSD/Modbus only /LS)
(VSD/Modbus only)
Capacity Values
Capacity
Cap. slide pos.
Vi ratio
Vi slide pos.
Yield
Control
(Not recip.)
(SAB157HR, SABflex, SABcube)
Control (Auto Vi only)
Table 3: Unisab III HMI menu tree
Operating Unisab III control
12/48
Operating manual - Unisab III
005650-en 2013.10
