Johnson Controls VFD66 Drive User Manual

VFD66 User Guide 23
Issue Number: 2 www.johnsoncontrols.com
Safety information Rating data
Mechanical
installation
Electrical
installation
De-rating
Keypad and
display
Parameters Diagnostics
Technical
specifications
UL Listing
6 Keypad and display
The keypad and display are used for the following:
• Displaying the operating status of the drive
• Displaying a fault or trip code
• Reading and changing parameter values
• Stopping, starting and resetting the drive
Figure 6-1 Keypad and display
6.1 Programming keys
The MODE key is used to change the mode of operation of the drive.
The UP and DOWN keys are used to select parameters and edit their values. In
manual input mode, they are used to increase and decrease the speed of the motor.
6.2 Control keys
The START key is used to start the drive in manual input mode.
The STOP/RESET key is used to stop and reset the drive.
M
