Johnson Controls York FREE MATCH EK Series User Manual

32
8.1 Cooling Capacity-temperature Curves
indoor tem
p
DB/WB 67 72 77 82 87 95 105 115
67/50 20460 20020 19360 18700 18040 17160 15840 13860
67/57
22000 21560 21120 20460 19580 18700 17380 15840
67/62
23760 23320 22660 21780 21120 20460 19140 17600
72/57
21780 21560 21120 20460 19580 18700 17380 15840
72/62
23760 23320 22660 21780 21120 20460 19140 17600
80/62
23760 23320 22660 21780 21120 20460 19140 17600
80/67
25740 25300 24640 23980 22880 22000 20900 19580
80/72
27060 26620 25960 25300 24420 23540 22660 21120
87/72
27060 26620 25960 25300 24420 23540 22660 21120
cooling temp.(humidity)40%
Capacity-temp.Curves
YSCC24FSAADG Performance Curves
YSCC24FSAADG
Capacity
Domestic Air Conditioner
