YORK INTERNATIONAL
8
FORM 150.62-NM6 (LS1)
One Field Provided Power Supply Circuit to the chiller. Field connections to Factory Provided Terminal Block (optional) or Non-Fused Discon-
nect Switch (optional). Includes Individual Branch Circuit Protection (Breakers) per electrical system
ELECTRICAL DATA – SINGLE POINT POWER SUPPLY CONNECTIONS WITH INDIVIDUAL SYSTEM
CIRCUIT BREAKERS – YCAL0090E_ - YCAL0134E_
TABLE 6 – SINGLE POINT POWER SUPPLY CONNECTIONS WITH INDIVIDUAL SYSTEM
CIRCUIT BREAK ERS
MODEL YCAL VOLT HZ
SINGLE POINT FIELD SUPPLIED WIRING
MCA
1
MIN N/F
DISC SW
2
D.E. FUSE CKT. BKR.
5
INCOMING (LUGS) WIRE RANGE
6
TERMINAL BLOCK (opt) NF DISC. SWITCH (opt)
MIN
3
MAX
4
MIN MAX
0090
200 60 385 600 450 450 450 450 (2) # 6 - 500 (3) 2/0 - 400
230 60 358 400 400 400 400 400 (2) # 6 - 500 (3) 2/0 - 400
380 60 208 250 225 250 225 250 # 10 - 300 (1) # 6 - 350
460 60 172 200 200 200 200 200 # 10 - 3/0 (1) # 6 - 350
575 60 137 150 150 150 150 150 # 10 - 3/0 (1) # 6 - 350
0094
200 60 420 600 450 500 450 500 (2) # 6 - 500 (2) 250 - 500
230 60 391 600 450 450 450 450 (2) # 6 - 500 (2) 250 - 500
380 60 227 250 250 250 250 250 # 10 - 300 (1 or 2) 3/0 - 500
460 60 188 250 200 225 200 225 # 10 - 300 (1) # 6 - 350
575 60 150 200 175 175 175 175 # 10 - 3/0 (1) # 6 - 350
0104
200 60 454 600 500 500 500 500 (2) # 6 - 500 (2) 250 - 500
230 60 422 600 450 450 450 450 (2) # 6 - 500 (2) 250 - 500
380 60 245 400 300 300 300 300 # 4 - 500 (1 or 2) 3/0 - 500
460 60 203 250 225 225 225 225 # 10 - 300 (1) # 6 - 350
575 60 162 200 175 175 175 175 # 10 - 3/0 (1) # 6 - 350
0114
200 60 483 600 600 600 600 600 (2) # 6 - 500 (2) 250 - 500
230 60 449 600 500 500 500 500 (2) # 6 - 500 (2) 250 - 500
380 60 261 400 300 300 300 300 # 4 - 500 (1 or 2) 3/0 - 500
460 60 216 250 225 225 225 225 # 10 - 300 (1 or 2) 3/0 - 500
575 60 172 200 200 200 200 200 # 10 - 300 (1) # 6 - 350
0124
200 60 553 800 600 600 600 600 (2) # 6 - 500 (2) 250 - 500
230 60 514 600 600 600 600 600 (2) # 6 - 500 (2) 250 - 500
380 60 299 400 350 350 350 350 # 4 - 500 (1 or 2) 3/0 - 500
460 60 247 400 300 300 300 300 # 10 - 300 (1 or 2) 3/0 - 500
575 60 197 250 225 225 225 225 # 10 - 300 (1) # 6 - 350
0134
200 60 611 800 700 700 700 700 (2) # 6 - 500 (2) 250 - 500
230 60 568 800 600 600 600 600 (2) # 6 - 500 (2) 250 - 500
380 60 330 400 350 350 350 350 # 4 - 500 (1 or 2) 3/0 - 500
460 60 271 400 300 300 300 300 # 10 - 300 (1 or 2) 3/0 - 500
575 60 218 250 225 225 225 225 # 10 - 300 (1) 6AWG - 3s50
