YORK INTERNATIONAL
9
FORM 150.62-NM6 (LS1)
SYSTEM #1 COMPRESSOR & FAN SYSTEM #2 FIELD SUPPLIED WIRING
COMPR. #1 COMPR. #2 COMPR. #3 FANS COMPR. #1 COMPR. #2 COMPR. #3 FANS
RLA LRA RLA LRA RLA LRA QTY FLA(EA) RLA LRA RLA LRA RLA LRA QTY FLA(EA)
87.2 500 87.2 500 — — 3 8.2 69.4 505 69.4 505 — — 3 8.2
80.8 500 80.8 500 — — 3 7.8 64.3 505 64.3 505 — — 3 7.8
46.6 305 46.6 305 — — 3 4.8 37.0 280 37.0 280 — — 3 4.8
38.5 250 38.5 250 — — 3 4.0 30.6 225 30.6 225 — — 3 4.0
30.8 198 30.8 198 — — 3 3.1 24.5 180 24.5 180 — — 3 3.1
87.2 500 87.2 500 — — 3 8.2 87.2 500 87.2 500 — — 3 8.2
80.8 500 80.8 500 — — 3 7.8 80.8 500 80.8 500 — — 3 7.8
46.6 305 46.6 305 — — 3 4.8 46.6 305 46.6 305 — — 3 4.8
38.5 250 38.5 250 — — 3 4.0 38.5 250 38.5 250 — — 3 4.0
30.8 198 30.8 198 — — 3 3.1 30.8 198 30.8 198 — — 3 3.1
69.4 505 69.4 505 69.4 505 4 8.2 87.2 500 87.2 500 — — 4 8.2
64.3 505 64.3 505 64.3 505 4 7.8 80.8 500 80.8 500 — — 4 7.8
37.0 280 37.0 280 37.0 280 4 4.8 46.6 305 46.6 305 — — 4 4.8
30.6 225 30.6 225 30.6 225 4 4.0 38.5 250 38.5 250 — — 4 4.0
24.5 180 24.5 180 24.5 180 4 3.1 30.8 198 30.8 198 — — 4 3.1
69.4 505 69.4 505 69.4 505 4 8.2 69.4 505 69.4 505 69.4 505 4 8.2
64.3 505 64.3 505 64.3 505 4 7.8 64.3 505 64.3 505 64.3 505 4 7.8
37.0 280 37.0 280 37.0 280 4 4.8 37.0 280 37.0 280 37.0 280 4 4.8
30.6 225 30.6 225 30.6 225 4 4.0 30.6 225 30.6 225 30.6 225 4 4.0
24.5 180 24.5 180 24.5 180 4 3.1 24.5 180 24.5 180 24.5 180 4 3.1
87.2 500 87.2 500 87.2 500 4 8.2 69.4 505 69.4 505 69.4 505 4 8.2
80.8 500 80.8 500 80.8 500 4 7.8 64.3 505 64.3 505 64.3 505 4 7.8
46.6 305 46.6 305 46.6 305 4 4.8 37.0 280 37.0 280 37.0 280 4 4.8
38.5 250 38.5 250 38.5 250 4 4.0 30.6 225 30.6 225 30.6 225 4 4.0
30.8 198 30.8 198 30.8 198 4 3.1 24.5 180 24.5 180 24.5 180 4 3.1
87.2 500 87.2 500 87.2 500 4 8.2 87.2 500 87.2 500 87.2 500 4 8.2
80.8 500 80.8 500 80.8 500 4 7.8 80.8 500 80.8 500 80.8 500 4 7.8
46.6 305 46.6 305 46.6 305 4 4.8 46.6 305 46.6 305 46.6 305 4 4.8
38.5 250 38.5 250 38.5 250 4 4.0 38.5 250 38.5 250 38.5 250 4 4.0
30.8 198 30.8 198 30.8 198 4 3.1 30.8 198 30.8 198 30.8 198 4 3.1
