9.5 Electrical Data
9-6
035-21786-100 Rev. 1 (0909)
Maximum Running
Conditions
kW
Amps
(1)
at 400 V
Amps
(2)
at 400V
040 34 55 69 121
050 40 66 82 155
060 49 80 101 188
080 55 89 112 140
100 80 131 164 178
(1) Nominal Running Amps at 7ºC Leaving Evaporator Liquid Temperature and 35ºC Leaving Condenser Liquid Temperature
(3) Unit maximum starting current , when last compressor starts.
(2) Maximum Running Amps is the maximum unit running current under the following conditions:
Supply voltage: 90% of rated voltage; Unit capacity: 100% at maximum operating condtions.
Nominal Running
Conditions
YCSE
Start up
Amps
(3)
Maximum Running
Conditions
kW
Amps
(1)
at 400 V
Amps
(2)
at 400V
040 34 59 77 125
050 42 73 95 161
060 52 87 115 195
080 68 117 154 144
100 84 145 190 184
(1) Nominal Running Amps at 7ºC Leaving Evaporator Liquid Temperature and 45ºC Condenser Saturation Temperature
(3) Unit maximum starting current , when last compressor starts.
(2) Maximum Running Amps is the maximum unit running current under the following conditions:
Supply voltage: 90% of rated voltage; Unit capacity: 100% at maximum operating c ondtions.
Nominal Running
Conditions
YCRE
Start up
Amps
(3)
