JOHNSON CONTROLS
7
FORM 155.34-CL2
ISSUE DATE: 12/10/2017
COMMISSIONING DATA SHEET (2/2) (STEAM SINGLE-EFFECT ABSORPTION CHILLER)
User:
Model: MFG.No.: User's machine code:
Running Data
Date: Measured by Specification Standard : : :
Steam
Steam condensate
control valve position
% Control panel
Steam primary pressure Pressure gauge ≤156 PSIG
Steam secondary pres-
sure
Pressure gauge
Steam temperature °F Thermometer ≤347°F
Drain outlet (back)
pressure
Pressure gauge
Drain temperature °F Thermometer ≤203°F
Steam consumption Flow meter
Chilled
Water
Inlet temperature °F Control panel
Outlet temperature °F Control panel
Inlet pressure PSIG Pressure gauge
Outlet pressure PSIG Pressure gauge
[3] Pressure drop PSIG DPM or calculation [4]
[1] Flow rate ft3/h FM or calculation [2]
Cooling
Water
Inlet temperature °F Control panel 68 ~ 89.6°F
Outlet temperature °F Control panel 68 ~ 89.6°F
Inlet pressure PSIG Pressure gauge
Outlet pressure PSIG Pressure gauge
[7] Pressure drop PSIG DPG or calculation [8]
[5] Flow rate ft3/h FM or calculation [6]
Absorption
Cycle
Generator press. (Gauge)
PSIG Compound gauge
Generator press. (Sensor)
mmHg
Control panel
Generator temperature °F Control panel ≤329°F
Generator concentration % Control panel
Absorber temperature °F Control panel
Refrigerant temperature °F Control panel
Liquid
Level
Generator - Level gauge
Absorber - Level gauge
Evaporator (Lower) - Level gauge
Evaporator (Upper) - Level gauge
NOTES:
Operating hours hours
Number of purge times times
Fill out each specication pressure drop according to the factory inspection report (actual value).
If differential pressure gauge (DPG) is not available, calculate each pressure drop.
If ow meter (FM) is not available, calculate each ow rate as below.
[1] = [2] x √[3]/[4] [5]=[6] x √[7]/[8]
LD20020
Same
Height
To Next Page
