Table 9: Physical data
Water volume
YHAU-C
Cold
insulation
area ft (m
2
)
Hot insulation
area ft (m
2
)
Radiation
heat loss (with
insulation,
ambient temp.
10°C) (kW)
Radiation heat
loss (without
insulation,
ambient temp.
10°C) (kW)
Chilled
water
(evap)
ft³ (m³)
Cooling
water (abs
and cond)
ft³ (m³)
Steam
(gen)
ft³ (m³)
30EXET 43.06 (4) 64.58 (6) 0.4 5.3 1.77 (0.05) 3.53 (0.1) 0.35 (0.01)
40EXET 53.82 (5) 75.35 (7) 0.6 7.0 2.12 (0.06) 3.88 (0.11) 0.71 (0.02)
50EXET 64.58 (6) 86.11 (8) 0.7 8.7 2.47 (0.07) 4.59 (0.13) 0.71 (0.02)
65EXET 64.58 (6) 96.88 (9) 0.9 11.3 3.18 (0.09) 5.65 (0.16) 0.71 (0.02)
80EXET 64.58 (6) 96.88 (9) 0.9 11.7 3.53 (0.1) 9.18 (0.26) 1.06 (0.03)
100EXET 75.35 (7) 107.64 (10) 1.1 14.6 4.24 (0.12) 10.59 (0.3) 1.41 (0.04)
130EXET 96.88 (9) 129.17 (12) 1.5 19.0 4.94 (0.14) 12.71 (0.36) 1.41 (0.04)
160EXET 107.64 (10) 150.69 (14) 1.8 23.3 5.65 (0.16) 15.19 (0.43) 1.77 (0.05)
200EXET 129.17 (12) 172.22 (16) 2.3 29.2 7.06 (0.2) 18.01 (0.51) 2.12 (0.06)
255EXET 129.17 (12) 182.99 (17) 2.5 31.1 12.01 (0.34) 31.08 (0.88) 2.47 (0.07)
320EXET 150.69 (14) 204.51 (19) 3.1 39.0 13.77 (0.39) 36.02 (1.02) 3.18 (0.09)
400EXET 182.99 (17) 236.81 (22) 3.9 48.8 16.60 (0.47) 42.02 (1.19) 3.53 (0.1)
500EXET 215.28 (20) 312.15 (29) 4.9 60.7 19.42 (0.55) 47.67 (1.35) 4.24 (0.12)
630EXW2ST 312.15 (29) 333.68 (31) 6.0 71.0 39.91 (1.13) 81.93 (2.32) 5.65 (0.16)
700EXW2ST 333.68 (31) 355.21 (33) 6.0 79.0 43.08 (1.22) 86.52 (2.45) 6.36 (0.18)
800EXW2ST 355.21 (33) 376.74 (35) 7.0 90.0 46.97 (1.33) 92.88 (2.63) 7.06 (0.2)
900EXW2ST 387.50 (36) 409.03 (38) 8.0 102.0 50.50 (1.43) 98.53 (2.79) 7.77 (0.22)
1000EXW2ST 419.79 (39) 441.32 (41) 9.0 113.0 54.74 (1.55) 104.88 (2.97) 8.48 (0.24)
1120EXW4ST 473.61 (44) 473.61 (44) 10.0 127.0 90.76 (2.57) 137.73 (3.9) 12.36 (0.35)
1250EXW4ST 505.90 (47) 505.90 (47) 11.0 142.0 95.70 (2.71) 145.85 (4.13) 13.42 (0.38)
1400EXW4ST 527.43 (49) 527.43 (49) 13.0 159.0 101.71 (2.88) 155.38 (4.4) 14.83 (0.42)
1500EXW4ST 559.72 (52) 559.72 (52) 14.0 170.0 105.59 (2.99) 162.09 (4.59) 15.89 (0.45)
1600EXW4ST 592.02 (55) 592.02 (55) 14.0 181.0 109.83 (3.11) 168.80 (4.78) 16.60 (0.47)
1680EXW4ST 613.54 (57) 613.54 (57) 15.0 189.0 114.07 (3.23) 175.51 (4.97) 17.66 (0.5)
1800EXW4ST 645.83 (60) 645.83 (60) 16.0 203.0 118.30 (3.35) 182.22 (5.16) 18.72 (0.53)
1900EXW4ST 678.13 (63) 678.13 (63) 17.0 214.0 122.19 (3.46) 188.93 (5.35) 19.42 (0.55)
2000EXW4ST 710.42 (66) 710.42 (66) 18.0 225.0 126.43 (3.58) 195.64 (5.54) 20.48 (0.58)
39YHAU-C Single Effect Steam-Fired Absorption Chiller
