Johnson Controls ZS-07 User Manual

5566019-BIM-B-1118
Johnson Controls Ducted Systems 25
ZS-06 through -12 high static motor - without powered convenience outlet
Size
(tons)
Volt
Compressors
(each)
OD fan
motors
(each)
Supply
blower
motor
Pwr exh
motor
Pwr
conv
outlet
Electric heat option
MCA
1
(amps)
MCA
1
with pwr
exh (amps)
Max fuse
2
/
breaker
3
size (amps)
Max fuse
2
/
breaker
3
size with
pwr exh
(amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
-06
(6)
208 11.2 84 18 2.1 6.8 5.5
None - - - 36.2 41.7 45 50
E09 6.8 1 18.9 36.2 41.7 45 50
E18 13.5 2 37.5 55.4 62.3 60 70
E24 18 2 50 71 77.9 80 80
E36 25.5 2 70.8 97 103.9 100 110
230 11.2 84 18 2.1 6.8 5.5
None - - - 36.2 41.7 45 50
E09 9 1 21.7 36.2 42.5 45 50
E18 18 2 43.3 62.6 69.5 70 70
E24 24 2 57.7 80.6 87.5 90 90
E36 34 2 81.8 110.8 117.6 125 125
460 5.6 44 9 1.26 3.4 2.2
None - - - 18.5 20.7 20 25
E09 9 1 10.8 18.5 20.7 20 25
E18 18 2 21.7 31.4 34.1 35 35
E24 24 2 28.9 40.4 43.1 45 45
E36 34 2 40.9 55.4 58.1 60 60
575 3.8 34 6 0.66 2.4 1.8
None - - - 12.3 14.1 15 15
E09 9 1 8.7 13.9 16.1 15 20
E18 18 2 17.3 24.6 26.9 25 30
E24 24 2 23.1 31.9 34.1 35 35
E36 34 2 32.7 43.9 46.1 45 50
-07
(7.5)
208 13.8 83.1 22 2.1 9.6 5.5
None - - - 44.9 50.4 50 60
E09 6.8 1 18.9 44.9 50.4 50 60
E18 13.5 2 37.5 58.9 65.8 60 70
E24 18 2 50 74.5 81.4 80 90
E36 25.5 2 70.8 100.5 107.4 110 110
230 13.8 83.1 22 2.1 9.6 5.5
None - - - 44.9 50.4 50 60
E09 9 1 21.7 44.9 50.4 50 60
E18 18 2 43.3 66.1 73 70 80
E24 24 2 57.7 84.1 91 90 100
E36 34 2 81.8 114.3 121.1 125 125
460 6.2 41 10 1.26 4.7 2.2
None - - - 21.2 23.4 25 25
E09 9 1 10.8 21.2 23.4 25 25
E18 18 2 21.7 33 35.8 35 40
E24 24 2 28.9 42 44.8 45 45
E36 34 2 40.9 57 59.8 60 60
575 4.9 33 8 0.66 3.6 1.8
None - - - 15.9 17.7 20 20
E09 9 1 8.7 15.9 17.7 20 20
E18 18 2 17.3 26.1 28.4 30 30
E24 24 2 23.1 33.4 35.6 35 40
E36 34 2 32.7 45.4 47.6 50 50
-08
(8.5)
208 14.5 98 23 3.03 9.6 5.5
None - - - 48.3 53.8 60 60
E09 6.8 1 18.9 48.3 53.8 60 60
E18 13.5 2 37.5 58.9 65.8 60 70
E24 18 2 50 74.5 81.4 80 90
E36 25.5 2 70.8 100.5 107.4 110 110
230 14.5 98 23 3.03 9.6 5.5
None - - - 48.3 53.8 60 60
E09 9 1 21.7 48.3 53.8 60 60
E18 18 2 43.3 66.1 73 70 80
E24 24 2 57.7 84.1 91 90 100
E36 34 2 81.8 114.3 121.1 125 125
460 6.3 55 10 1.6 4.7 2.2
None - - - 22.1 24.3 25 30
E09 9 1 10.8 22.1 24.3 25 30
E18 18 2 21.7 33 35.8 35 40
E24 24 2 28.9 42 44.8 45 45
E36 34 2 40.9 57 59.8 60 60
575 6 41 9 1.35 3.6 1.8
None - - - 19.8 21.6 25 25
E09 9 1 8.7 19.8 21.6 25 25
E18 18 2 17.3 26.1 28.4 30 30
E24 24 2 23.1 33.4 35.6 35 40
E36 34 2 32.7 45.4 47.6 50 50
