Johnson Controls ZS-07 User Manual

5566019-BIM-B-1118
Johnson Controls Ducted Systems 29
ZS-06 through -12 high static motor - with powered convenience outlet
Size
(tons)
Volt
Compressors
(each)
OD fan
motors
(each)
Supply
blower
motor
Pwr exh
motor
Pwr
conv
outlet
Electric heat option
MCA
1
(amps)
MCA
1
with pwr
exh (amps)
Max fuse
2
/
breaker
3
size (amps)
Max fuse
2
/
breaker
3
size with
pwr exh
(amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
-06
(6)
208 11.2 84 18 2.1 6.8 5.5 20
None - - - 46.2 51.7 50 60
E09 6.8 1 18.9 46.2 51.7 50 60
E18 13.5 2 37.5 67.9 74.8 70 80
E24 18 2 50 83.5 90.4 90 100
E36 25.5 2 70.8 109.5 116.4 110 125
230 11.2 84 18 2.1 6.8 5.5 20
None - - - 46.2 51.7 50 60
E09 9 1 21.7 48.1 55 50 60
E18 18 2 43.3 75.1 82 80 90
E24 24 2 57.7 93.1 100 100 100
E36 34 2 81.8 123.3 130.1 125 150
460 5.6 44 9 1.26 3.4 2.2 20
None - - - 23.5 25.7 25 30
E09 9 1 10.8 24 26.8 25 30
E18 18 2 21.7 37.6 40.4 40 45
E24 24 2 28.9 46.6 49.4 50 50
E36 34 2 40.9 61.6 64.4 70 70
575 3.8 34 6 0.66 2.4 1.8 20
None - - - 16.3 18.1 20 20
E09 9 1 8.7 18.9 21.1 20 25
E18 18 2 17.3 29.6 31.9 30 35
E24 24 2 23.1 36.9 39.1 40 40
E36 34 2 32.7 48.9 51.1 50 60
-07
(7.5)
208 13.8 83.1 22 2.1 9.6 5.5 20
None - - - 54.9 60.4 60 70
E09 6.8 1 18.9 54.9 60.4 60 70
E18 13.5 2 37.5 71.4 78.3 80 80
E24 18 2 50 87 93.9 90 100
E36 25.5 2 70.8 113 119.9 125 125
230 13.8 83.1 22 2.1 9.6 5.5 20
None - - - 54.9 60.4 60 70
E09 9 1 21.7 54.9 60.4 60 70
E18 18 2 43.3 78.6 85.5 80 90
E24 24 2 57.7 96.6 103.5 100 110
E36 34 2 81.8 126.8 133.6 150 150
460 6.2 41 10 1.26 4.7 2.2 20
None - - - 26.2 28.4 30 30
E09 9 1 10.8 26.2 28.4 30 30
E18 18 2 21.7 39.3 42 40 45
E24 24 2 28.9 48.3 51 50 60
E36 34 2 40.9 63.3 66 70 70
575 4.9 33 8 0.66 3.6 1.8 20
None - - - 19.9 21.7 20 25
E09 9 1 8.7 20.4 22.6 25 25
E18 18 2 17.3 31.1 33.4 35 35
E24 24 2 23.1 38.4 40.6 40 45
E36 34 2 32.7 50.4 52.6 60 60
-08
(8.5)
208 14.5 98 23 3.03 9.6 5.5 20
None - - - 58.3 63.8 70 70
E09 6.8 1 18.9 58.3 63.8 70 70
E18 13.5 2 37.5 71.4 78.3 80 80
E24 18 2 50 87 93.9 90 100
E36 25.5 2 70.8 113 119.9 125 125
230 14.5 98 23 3.03 9.6 5.5 20
None - - - 58.3 63.8 70 70
E09 9 1 21.7 58.3 63.8 70 70
E18 18 2 43.3 78.6 85.5 80 90
E24 24 2 57.7 96.6 103.5 100 110
E36 34 2 81.8 126.8 133.6 150 150
460 6.3 55 10 1.6 4.7 2.2 20
None - - - 27.1 29.3 30 35
E09 9 1 10.8 27.1 29.3 30 35
E18 18 2 21.7 39.3 42 40 45
E24 24 2 28.9 48.3 51 50 60
E36 34 2 40.9 63.3 66 70 70
575 6 41 9 1.35 3.6 1.8 20
None - - - 23.8 25.6 25 30
E09 9 1 8.7 23.8 25.6 25 30
E18 18 2 17.3 31.1 33.4 35 35
E24 24 2 23.1 38.4 40.6 40 45
E36 34 2 32.7 50.4 52.6 60 60
