POLY V BELT 430J6 REPLACEMENT PROCEDURE (JPS)

Tools required:

u Philips

screwdriver

u Hex key (4mm)

Procedure:

1. Loosen the screws

from the side cover with

the screwdriver.

2. Loosen the 430J6 and

430J8 belts.

3. Loosen the screws

from the front pulley by

using hex key (4mm).

4. Replace the 430J6

belt with a new one.

5. Tighten the screws from the front pulley by using the hex

key (4mm).

6. Install the 430J6 and 430J8 belts onto the front and rear

pulleys.

7. Install the side cover.

3-12 Revision: 1.0 Date: 2001/06/01
