T500 Series Non-Programmable Thermostats Product/Technical Bulletin
3
!
CAUTION:
Equipment Damage Hazard.
Before applying power, make
all wiring connections and
check the connections.
Short-circuited or improperly
connected wires may result in
permanent damage to the
unit.
Figure 3
:
Separating the T500 from the Base
Mount
Figure 4: Mounting the Base
