MA7:13
V Range 502 l 652 l 802 Maintenance Manual
Johnston Sweepers Limited
Chapter - Remove and Refit Procedures
(1) Body Prop - Ensure autoprop has
engaged when body is raised.
(2) Water pump.
(3) Channel brush - (i) Grease when
renewing brush stock.
(4) Wide sweep brush - (i) Grease when
renewing brush stock.
(5) ‘Z’ drive gearbox and Fluid Coupling.
LUBRICATION DIAGRAM
Refer to Maintenance Schedules for lubrication intervals
(6)
Supawash hose reel.
(7) Wanderhose - (i) Rotate boom to
distribute grease around bearing
(8)
Hopper tip pivot
(9) Rear door
(10) Nozzle wheel
(11) Body raise cylinder
VT - Twin Engine
Approved Lubricants
Capacity ISO Oil Grade
Johnston
Part No.
Fuchs
(A) Hydraulic System 65L - 94-12 -
(B) Gearbox 2.5L API GL-4 94-67 -
(C) Supawash Pump 0.37L API GL-4 94-67 -
(D) Fluid Flywheel 4.85L - 94-12 -
(E) Engine 14L
ACEA
E3 - E5
94-23 -
(F) Drive Splines - - 94-24
Kluberpaste
(46 MR 401)
(G) Antifreeze 15L - 39664 -
(H)
Chassis PAS - Auto
Gearbox
See Chassis
Handbook
- 39661 -
Grease Points - 94-69 -
Battery Terminals - - - Petroleum Jelly
The above oils are those approved by Johnston Sweepers.
Other manufacturer’s oils must be of equivalent grade.
Item Description Item Description
