MA3:1
V Range 502 l 652 l 802 Maintenance Manual
CHAPTER
3
Johnston Sweepers Limited
Electrical System
Chapter - Electrical System
All Copyright and rights are the property of Johnston Sweepers Ltd
Table of Contents
Section Page
Introduction
General Description 3 : 2
System Description 3 : 2
Component Identification
Systems Locker 3 : 3
Johnston Visual Module (JVM)
Engine / Chassis Control 3 : 4
System Can - CANOPEN 3 : 4
CAN Line Setup 3 : 4
VDB Communication Line Schematic 3 : 5
How to update control system software 3 : 6
Data capture download 3 : 12
Circuit Diagrams 3 : 16
