V Range 502 l 652 l 802 Maintenance Manual
MA8:14
Chapter - Fault Diagnosis
Truck Mounted Sweepers Emergency (EMCY) Codes (continued)
Revision 05 Release Date: 29.06.2016
EMCY
Code Type Description of Fault
System Locker Node - ID 16
Area of Fault
PowaPak Node - ID 22
Area of Fault
Hydrostatic Node - ID 24
Area of Fault
Hopper Node - ID 18
Area of Fault
36864 Digital Output 1 Short to ground WSB Motor Engine Starter Solenoid AntiSkid Valve Rear Door Open
36865 Digital Output 2 Short to ground CB 1 Motor Autolube Level Switch/ESOS Valve(85kW) V41 Rear Door Close
36866 Digital Output 3 Short to ground CB 1 retract Engine Heat Start V42 Rear Door Release
36867 Digital Output 4 Short to ground CB 1 extend Discharge Audible Warning Discharge Audible Warning Rear Door Lock
36868 Digital Output 5 Short to ground CB 2 motor Water Supply Shut-off Water Supply Shut-off Hopper Raise
36869 Digital Output 6 Short to ground CB 2 retract Rotatilt #1+ Rotatilt #1+ Hopper Lower
36870 Digital Output 7 Short to ground CB 2 extend Rotatilt #1- Rotatilt #1- Not Used
36871 Digital Output 8 Short to ground WSB Spraybar Rotatilt #2+ Rotatilt #2+ Cowl Worklight
36880 Digital Output 9 Short to ground CB 1 Water Rotatilt #2- Rotatilt #2- Rear Beacons
36881 Digital Output 10 Short to ground Gutter Spray 1 Not Used Used as Input Supawash
36882 Digital Output 11 Short to ground CB 2 Water Used as Input Hydrostatic Reverse Output Used as Input
36883 Digital Output 12 Short to ground Gutter Spray 2 Ignition Output Aux engine Gearbox Sensors Output Used as Input
36884 Digital Output 13 Short to ground Nozzle 1 Water Combivak Nozzle #1 Not Used Used as Input
36885 Digital Output 14 Short to ground Nozzle 2 Water Combivak Nozzle #2 Fan Control Used as Input
36886 Digital Output 15 Short to ground Body Discharge Work Lamp RH Work Lamp RH Auto Lube Power
36887 Digital Output 16 Short to ground Additional Water Work Lamp LH Work Lamp LH External Discharge Pump Run
36896 Analogue Output Short to ground WSB Balance Regulator LH WSB Balance Regulator RH WSB Balance Regulator RH Not Used
36897 H-Bridge Output Short-Circuit
Rear Warning/Work Lights Not Used Not Used Powaboom Raise/Lower
4096 Engine Fault Low Oil Pressue
4097 Hydrostatic Gearbox/ Engine Fault Low Oil Level
4098 Engine Fault Cooltant Temp High
4099 Engine Fault Loss of Speed Signal
4100 Engine Fault Water in Fuel
4101 Engine Fault Cooltant Temp Shutdown
4102 Engine Fault Low Fuel Shutdown
