JoinTech JT709A - Wake-Up Methods

17 / 41
swiping the
RFID card successfully
Device locks automatically
Send commands to unlock
the device via various
channels (SMS, RFID card,
Bluetooth, platform, etc.)
but did not pull out the lock
rope
if the lock rope is not pulled out in 10 seconds after unlocking,
the buzzer will sound once every second until the lock rope is
inserted. If lock rope is not pulled out in 60 seconds after
unlocking, the device will automatically lock and the buzzer will
stop ringing.
Insert lock rope but does
not lock automatically
After unlocking, remove and insert the lock rope within a short
period of time (1 second). If the device does not detect that lock
rope is inserted, the buzzer will sound once every second until
user pulls out the lock rope, and then inserts lock rope, then the
buzzer stops ringing and the device is automatically locked.
Wake-up Methods
Wake-up source (wake-up method)
Description (prerequisite, the device is
powered on and in sleep status)
Vibration
wake up and work for 10 minutes, if without other
wake-up source during the 10 minutes, then sleep;
Open back cap
wake up and work for 10 minutes, if without other
wake-up source during the 10 minutes, then sleep;
Pull out lock rope
wake up and work for 10 minutes, if without other
wake-up source during the 10 minutes, then sleep;
Charging
wake up and work for 10 minutes, if without other
wake-up source during the 10 minutes, then sleep;
Swipe RFID card（Authorized or unauthorized
RFID card）
wake up and work for 10 minutes, if without other
wake-up source during the 10 minutes, then sleep;
SMS, calling
(Default VIP number, non-VIP number can be
configured)
wake up and work for 10 minutes, if without other
wake-up source during the 10 minutes, then sleep;
RTC timing
Wake up at a preset time interval and go to sleep
after uploading a position data;
Bluetooth commands
wake up and work for 10 minutes, if without other
wake-up source during the 10 minutes, then sleep;
