33
3
Electrical system
502 71 23-01
Replacing the generator
Replace the generator if it does not prov-
ide sufficient voltage.
Place the new generator in position and
centre it before tightening the screws.
Replacing the generator
The generator must be replaced if the
voltage proves to be insufficient when
checked.
The generator is placed behind the
flywheel.
Remove the screws and lift off the gene-
rator.
Place the new generator in position
against the crankcase. Check that the
cable is not clenched.
Use mandrel No. 502 71 23-01 to centre
the generator to the crankshaft.
Tighten the screws.
