15
Safety equipment
1
Dismantling mod. 625/630/670
Press out the fitted pin and dismantle the
cover.
Dismantle the spring and throttle control
lock.
Fitting mod. 625/630/670
Fit the throttle control lock in the reverse
order to dismantling.
Dismantling mod. 2095
Dismantle the handle half.
Dismantling mod. 625/630/670
Press out the fitted pin approx. 13-14 mm
so that the throttle control lock comes
loose.
Dismantle the covers by means of pres-
sing a screwdriver into the back edge of
the covers.
If the handle is electrically heated see
chap. 3 ”Electrical system”.
Press out the sprung tubular pin which is
located behind the cover far enough so
that the spring and the throttle control
lock can be lifted off.
Fitting mod. 625/630/670
Replace damaged or worn parts and fit in
the reverse order to dismantling.
NOTE!
The sprung tubular pin should go through
the spring eyelet.
Dismantling mod. 2095
Remove the screws and lift off the handle
half.
