Jonsered CS2186 - Lubricating cutting equipment

12 – English
SERVICE DATA
▲ = Lubricate with two-stroke oil.
■ = Lubricate with chain oil.
● = Lubricate with grease.
The figures next to parts screwed on indicate
the tightening torque Nm.
Key to diagrams
●
●
●
10
10
14
5
■
▲
▲
●
8
●
8
6
15
