26 – English
MAINTENANCE
Restoring from service position
To restore the machine from the service position,
reverse the sequence “Placing in Service position“.
2
1
7. Lift off the drive belt (1). Then pull out the pin
(2).
Take care not to get your hand trapped.
8. Pull the frame forwards and insert the pin.
9. Grasp the front edge of the cutting unit, pull out
and raise into the service position.
