3 Installation
Compressed air quality
Max. 15 barCompressed
air network
(main air)
Min. 5 bar
Compressed air quality according to ISO 8573-1
Solids Particle size/density 5
1
≙ ≤ 5 µm
Water Dew point 2
1
≙ -40 °C
Oil mg/m
3
4
1
≙ ≤ 5 mg/m
3
1 Quality classes
ATTENTION!
Remove the filter (on the front) from the pneu-
matic cylinder before painting.
ADVICE!
To avoid functional problems, the quality of the
compressed air supply must match the specifica-
tions provided, as a minimum.
12 MUB 002 013 M30 (REV--) 02-2024
