4 Operation
4.2 Open/closed status – closed and locked, pre-departure
inspection
1 Remote display 3 Lever in locked position
2 Second lock
(latch) closed
Remote display (1): lights up green
ADVICE!
Perform a pull test on the second lock (2): latch
must move under tension
The light must indicate “off-on-off-on” during
the rope pull test.
Lever (3) is in locked position
14 MUB 002 013 M30 (REV--) 02-2024
