8
Copyright©2020 Jovision Technology Co., Ltd. All rights reserved.
1.2. Front Panel and Rear Panel
Note: This model is for reference only, appearance and ports may vary due to different models.
1.3. Connection Sample
① Power LED
② HDD LED
③ Network LED
④ USB Port
① Audio In
② Audio Out
③ VGA
④ HDMI
⑤ RJ45
⑥ USB Port
⑦ RS485
⑧ On/Off Switch
⑨ DC Power
