position. (See Figure 7)
Before attempting to adjust the seat ensure that engine of the Off Highway
Recreational Vehicles is stopped.
Never operate this Off Highway Recreational Vehicles when the provided
seat is not securely fastened, to do so could result in a strong possibility of
severe personal injury or loss of life. Before attempting to adjust the seat
ensure that engine of Off Highway Recreational Vehicles is stopped.
Parking
Park brake “OFF” Park brake “On”
a. Pull the park brake lever up so that the unit can engage park brake.
b. To release the unit, press button on front end of parking lever then push the parking
lever to the bottom.
c. Adjust the parking cable if necessary. As the figure shown, adjust the adjustment nuts
to make sure the cable tight, and then tighten lock nuts.
Gear Shift
Cable adjustment nuts
Cable lock nut
Figure 9
Figure 8
Figure 10
