1. Operate the gear shift as the picture shown. and the max speed in every gear
position is shown as the following form（see Figure 11）
Gear position Max speed
1st 26 km/h
2nd 37km/h
3rd 50 km/h
4th 80km/h
R 32 km/h
Figure 13
2. Adjust the adjustment nuts shown in the above picture, if necessary. To make sure
the shift lever right position. (see Figure 12)
Break-in
The first month is most important in the life of your vehicle. Proper operation during this
break-in period will help assure maximum life and performance from your new vehicle.
The following guidelines explain proper break-in procedures.
1. After the engine starts, the engine is not allowed in high speed in the neutral gearshift.
2. Drive vehicle from stop to low speed slowly.
3. Avoid braking strongly.
4. Do not exceed the vehicle speed on the below schedule
The speed of vehicle The first 1000 km
Max speed in each gear
1st Gear 15 km/h
2nd Gear 25km/h
3rd Gear 40 km/h
4th Gear 70km/h
Figure 14
Starting and Operating Instructions
a. Before starting the engine, be sure that the driver is seated properly in the Off
Highway Recreational Vehicles and tighten the seatbelt.
b. Testing the Off Highway Recreational Vehicles in a open place at the beginning to
learn how to start, turn and stop.
c. Operate the Off Highway Recreational Vehicles slowly until you are familiar with it.
d. The turning radius of this Off Highway Recreational Vehicles is small and agile, so the
centrifugal force is very high when turning at high speed. Slow down to a more
controllable speed when turning to prevent the Off Highway Recreational Vehicles from
Adjustment nuts
Lock nuts
Connect to
shift lever
Figure 11
Figure 12
