Joyner JNSZ650DLB - Clutch， Shifter Shaft and Rocker Arm

To Next Page

To Previous Page

CLUTCH， SHIFTER SHAFT AND ROCKER ARM

No. ERP Code Code name Description Q'ty

1 02.DLJ.QST160HH14 QST160HH14 Clutch pressure plate 1

02.DLJ.LJ462Q—1—100502

LJ462Q—1—1005024D Clutch cover bolt 2

3 02.DLJ.9074.15—M8X16 9074.15—M8X16 Bolt tab M8×16 4

4 02.DLJ.859—W8 859—W8 Light gage spring washer8 6

5 02.DLJ.DST160A71 DST160A71 Clutch plate 1

6 02.DLJ.MQC4-1701510 MQC4-1701510 Clutch release bearing 1

7 02.DLJ.MQC4-1701501 MQC4-1701501 Release bearing carrier 1

8 02.DLJ.MQC4-1701022 MQC4-1701022 Circlip 2

9 02.DLJ.MQC4-1701040 MQC4-1701040 Clutch fork 1

10 02.DLJ.MQC4-1701019 MQC4-1701019 Bushing ring 2

11 02.DLJ.MQC4-1701018 MQC4-1701018 Tension spring 1

12 02.DLJ.4T06C-1701016 4T06C-1701016 Clutch action arm 1

13 02.DLJ.GB5789-86 AM8X35 GB5789-86 AM8X35 Bolt AM8×35 1

14 02.DLJ.GB97.1-85 8-200HV GB97.1-85 8-200HV Washer8-200HV 1

15 02.DLJ.GB6170-86 M8 GB6170-86 M8 Nut M8 1
