Joyner JNSZ650DLB - Page 65

6
02.DLJ.270Q－01403 270Q－01403
Filler cap ruuber washer 1
7
02.DLJ.270Q－01012B 270Q－01012B
Seal ring of cylinder head cover 1
8
02.DLJ.9074.17－M8X30 9074.17－M8X30
Unit bolt M8×30 1
9 02.DLJ.QTB15-M8 QTB15-M8
Nut M8－8
5
10
02.DLJ.93－φ8 93－φ8
Spring washer φ8 5
11
02.DLJ.270Q－01017 270Q－01017
Thermostat housing 1
13
02.DLJ.270Q－01016 270Q－01016
Thermostat gasket 1
14
02.DLJ.270Q－01015 270Q－01015
Thermostat 1
15
02.DLJ.270Q－01100 270Q－01100
Cylinder head and camshaft bearing
part
16
02.DLJ.270Q－01109 270Q－01109
Camshaft bearing bushing cap bolt 8
17
02.DLJ.270Q－01007 270Q－01007
Valve rocker arm shaft 4
18
02.DLJ.898－M8X25 898－M8X25 Stud AGM8×25－8.8
4
19
02.DLJ.899－M8X28 899－M8X28 Stud AGM8×28－8.8
1
20
02.DLJ.270Q－01104 270Q－01104
Inlet valve guide 2
21 02.DLJ.QTB40-φ 6×14 QTB40-φ 6×14 Locating pin φ 6×14 6
22
02.DLJ.270Q－01105 270Q－01105
Exhaust valve guide 2
23
02.DLJ.899－B 899－B
bolt 1
24
02.DLJ.270Q－01023A 270Q－01023A
Hexagon -headed taper plug 1
25
02.DLJ.898－M8X20 898－M8X20 Stud AGM8-M8×20－8.8
4
26
02.DLJ.270Q－01018 270Q－01018
Minor water pipe 1
27
02.DLJ.270Q－01102 270Q－01102
Intake valve seat 2
28
02.DLJ.270Q－01103B 270Q－01103B
Exhaust valve seat 2
29
02.DLJ.270Q－01019B 270Q－01019B
Water Temperature sender unit 1
30
02.DLJ.270Q－01013 270Q－01013
Front Semi-Circle Oil Seal 1
31
02.DLJ.270Q－01014 270Q－01014
Rear Semi-Circle Oil Seal 1
32
02.DLJ.270Q－01022 270Q－01022
Cylinder head bolt 6
33 02.DLJ.GTB30-φ21×φ11×3 GTB30-φ21×φ11×3 head bolt washer φ21×φ11×3 6
34
02.DLJ.9074.17－M8X28 9074.17－M8X28
Bolt assembly M8×28 2
35
02.DLJ.276Q－01021 276Q－01021
Cylinder head gasket 1
36
02.DLJ.270Q－01025 270Q－01025
Rubber blanking plug 1
37
02.DLJ.ZB/TT32005.1－88 ZB/TT32005.1－88
hose clamp 1
38
02.DLJ.270Q－01024 270Q－01024
Exhaust pipe gasket 1
39
02.DLJ.93－W8 93－W8
Washer8 4
40 02.DLJ.QTB15-M8 QTB15-M8
Nut M8－8
4
