Now mixing will be activated only when this Flight Mode is
selected. Note: If all Flight Mode positions are critical (pose
significant risk for the aircraft), then use one of the other
switches for testing purposes.
4. Touch PAGE and select the type of mix (Normal, Include,
Origin) and whether or not the Trim feature is to be enabled.
5. Touch PAGE until the mixing percentage screen is displayed.
Move the Flight Mode switch (or the switch that was selected
in Step 3 above) until POS1 appears over the percentages.
6. Set the mix offset (if any) and set the mixing percentages as
may be appropriate for the desired mixing activity. Thoroughly
ground test the mix.
7. Fly the aircraft and test the mixer by selecting the Flight Mode
(or other switch that was used in step 3 above) that was indi-
cated as using POS1. Adjust the mixing parameters in the
Function Code that was used in step 1 to obtain the desired
results.
8. You may now return to the Programmable Mix (51-58) to pro-
gram the POS0 settings and/or to assign the mixing values to
other Flight Modes. Remember, in order to be able to turn mix-
ing off, either POS0 or POS1 values must be set to zero.
Trimmer Function (Flap)
The flap lever, when active, raises or lowers the flaps in unison
with one another.
To activate the flap lever, touch the PAGE key to get to the neces-
sary trim function, touch the
ACT key under “flap.”
This portion of the
LCD screen will appear as follows:
Note: The flap trimmer function also appears when normal,
flaperon or elevon wing type is selected and can be inhibited or
activated as described above.
With dual elevator active, the right side level can be utilized as
alivator trim lever (elevator halves in opposite directions). This is
helpful for adjusting loop tracking.
26
10X MANUAL Airplane
